Taipei, Taiwan – AAEON, a leader in industrial PC solutions, has released the EPIC-BTS9, the latest addition to its 4″ EPIC Board portfolio, making it the company’s first single-board to support up to 65W socket-type CPUs from the new Intel Core Series 2 socket-type processors (formerly Bartlett Lake).
While primarily developed for use with Intel Core Series 2 processor CPUs, which grant up to 24 cores and 32 threads of processing performance, the EPIC-BTS9 is also pin-to-pin compatible with 12th, 13th, and 14th Gen Intel Core processors, up to 65W.
In addition to its cross-generation CPU compatibility, the EPIC-BTS9 is available in SKUs equipped with a choice Intel R680E, Q670E, or H610E chipsets, with the board’s Intel R680E Chipset SKU offering ECC (Error-Correcting Code) support to the 64GB of dual-channel DDR5 system memory on offer via two SODIMM slots.
The EPIC-BTS9’s I/O comes with a total of four LAN ports, three running at 2.5GbE with hardware timestamping, and one at 1GbE speed. These are joined by two USB Type-A ports offering USB 3.2 Gen 1 and Gen 2 signals, respectively. Rounding off its physical I/O is a HDMI 2.0 port.
For internal connectors, AAEON’s positioning of the board for industrial AI and smart manufacturing makes sense, with dual COM connectors for RS-232/422/485, an 8-bit GPIO, and SMBus. I2C is also available when running Windows, rather than Ubuntu, and can be changed by BOM. The board also offers headers for both VGA and eDP 1.4, the reasoning for which being to allow simplified integration with existing industrial display panel setups.
The EPIC-BTS9 offers versatile expansion options, with the main standout being an eight-lane PCIe Gen 4 slot, which can be used for AI accelerators, graphic capture cards, or additional storage needs. Meanwhile, the board hosts M.2 2280 M-Key, M.2 3052 B-Key, and M.2 2230 E-Key slot for additional storage and wireless communication module installation.
The EPIC-BTS9 is now in mass production, with samples available for order on the AAEON eShop. Meanwhile, more information and detailed specifications can be found on the AAEON website’s product page.
